| SWITCH DLINK | |
|---|---|
| NUMBER OF PORTS | 16 10/100/1000 Gigabit ports |
| SWITCHING FABRIC | 32Gbps |
| Standard | • IEEE 802.3 10BASE-T Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • ANSI/IEEE 802.3 NWay auto-negotiation • IEEE 802.3x Flow Control |
| Data Transfer Rates | • Ethernet: • 10 Mbps (half duplex) • 20 Mbps (full duplex) • Fast Ethernet: • 100 Mbps (half duplex) • 200 Mbps (full duplex) • Gigabit Ethernet: • 2000 Mbps (full duplex) |
| Network Cables | UTP CAT 3, 4, 5/5e (100 m max) EIA/TIA-586 100-ohm STP (100 m max) 100BASE-TX, 1000BASE-T UTP CAT 5/5e (100 m max) EIA/TIA-568 100-ohm STP (100 m max) |
| Media Interface Exchange | Auto MDI/MDIX adjustment for all ports |
| LED Indicators | • Power LED • 16 Link/Activity/Speed LEDs (one per port) |
| Transmission Method | Store-and-forward |
| MAC Address Table | 8k |
| MAC Address Learnin | Automatic update |
| Packet Filtering/Forwarding Rates (half duplex) | Ethernet: 14,880 pps per port Fast Ethernet: 148,800 pps per port Gigabit Ethernet: 1,488,000 pps per port |
| RAM Buffer | 2Mbits |
| Power Consumption | • Power on (standby): AC input: 2.64 Watts • Power max.: AC input: 9.00 Watts |
| MTBF | • 319,267 hours |
| DIMENSIONS (L X W X H) | • 231 x 158 x 46 mm (9.1 x 6.2 x 1.8 inches) |
| Weight | • 0.58 kg (1.28 pounds) |
Thông số kỹ thuật
Mô tả sản phẩm
Gigabit on Every Port
The 16-Port Unmanaged Gigabit Switch series brings the speed of Gigabit Ethernet to each and every port for a truly high-speed network. If your network has a mix of legacy and modern computing capabilities, each port allows for standard Ethernet, Fast Ethernet, or Gigabit Ethernet connections. You have the latest technology available to every computer and device connected to your network.
Innovative Design
The sleek plastic case of the DGS-1016A series is an industry first for a Gigabit SOHO/SMB switch. Using a compact desktop style helps reduce heat levels and allow for a fanless design, making the switches silent, as well as economical. The 16-Port Unmanaged Gigabit Switch series is small, lightweight, wall-mountable, and ideal for any business with big needs and a small budget.
Conserves Energy
The 16-Port Unmanaged Gigabit Switch series helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save substantial amounts of power by cutting power usage for unused ports or any ports connected to computers that have been shut down. It can also detect connected cable lengths, and adjusts power usage accordingly, helping you save energy without affecting networking performance.
Think Green
The DGS-1016A 16-Port Unmanaged Gigabit Switch series makes use of D-Link Green Ethernet technology, providing more energy savings and a longer product life, without sacrificing operational performance or functionality. These environmentally friendly switches are also RoHS compliant, use recyclable packaging, and minimize the use of harmful substances.
