| POWER COOLERMASTER | |
|---|---|
| MODEL | MPY-7501-AFAAG |
| PFC | Active PFC (>0.95 typical) |
| ATX VERSION | ATX 12V V2.31 |
| INPUT VOLTAGE | 100-240V |
| INPUT CURRENT | 12-6A |
| INPUT FREQUENCY | 50/60Hz |
| DIMENSIONS (L X W X H) | 160 x 150 x 86 mm |
| FAN SIZE | 120mm |
| FAN BEARING | LDB |
| EFFICIENCY | 90% Typically |
| ERP 2014 LOT 3 | Yes |
| OPERATING TEMPERATURE | 0-45°C |
| MTBF | >100,000 Hours |
| PROTECTIONS | OVP, OPP, UVP, SCP, OTP |
| REGULATORY | CCC, CE, TUV-SUD, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| ATX 24-PIN CONNECTORS | 1 |
| EPS 4+4 PIN CONNECTORS | 1 |
| EPS 8 PIN CONNECTOR | 1 (for updated models) |
| SATA CONNECTORS | 8 |
| PERIPHERAL 4-PIN CONNECTORS | 6 |
| FDD CABLE 4-PIN CONNECTORS | 1 |
| PCI-E 6+2 PIN CONNECTORS | 4 |
| WATTAGE | 500 to 750W |
| 80 PLUS | Gold |
| MODULAR | Full Modular |
| SERIE | MWE Gold Series |
Thông số kỹ thuật
Mô tả sản phẩm
BE BOLD, POWER WITH GOLD
- 80 PLUS GOLD CERTIFIED
- 120MM LDB FAN
- ADVANCED CIRCUITRY
- FULLY MODULAR CABLING
MWE GOLD 650 FULLY MODULAR
Behold the 80 Plus Gold rated, fully modular MWE Gold. This power supply unit delivers consistent 90% efficiency, low temperatures, and quiet operation. High quality, heat resistant components have been used to achieve gold level performance at temperatures up to 45°C. The Silencio fan and exclusive LDB bearing provides nearly silent cooling at no loss to system performance and a longer lifespan. Flat cables improve airflow by reducing cable bulk and a single +12V line ensures all components are fed the same stable output regardless of which cable you use. Be bold, power with gold.
FULLY MODULAR CABLES
Fully customizable cabling reduces clutter, increases airflow, and improves overall thermal performance.
ADVANCED CIRCUITRY
The MWE Gold's full-bridge design coupled with LLC, Synchronous, and DC to DC topology technologies offers reliable and stable voltage outputs.
