Switch D-Link 24-Port 10/100Mbps DES-1024D

Chưa có đánh giá nào
3265 lượt xem

Mã sản phẩm : DES-1024D
Thương hiệu : D-LINK

850.000^₫ [Đã bao gồm VAT]

Số lượng
Còn hàng

Mua ngay Thêm vào giỏ hàng

DES-1024D

24-Port Fast Ethernet Desktop/Rackmount Switch In Metal Casing

The DES-1024D is a 24-Port 10/100 Unmanaged Desktop Switch that combines ease of use with unsurpassed performance, resulting in an exceptional value for any network administrator who wants the best possible solution at the best price. The DES-1024D is a true Plug-and-Play device, featuring Auto Speed Sensing, Auto-negotiation, and Auto MDI/MDI-X Crossover.

Cam kết hàng chính hãng
Cam kết hàng nguyên tem, nguyên kiện, mới 100%
Bảo hành theo tiêu chuẩn NSX
Giao hàng toàn quốc
Bảo hành nhanh chóng

HOTLINE & ZALO TƯ VẤN:

Mr. Minh Trí: 093.855.3309

Ms. Mai Duyên: 093.143.9459

Ms.Hồng Trinh: 093.207.0746

Mr. Thành Tâm: 093.891.0559

Mr.Văn Sang: 090.397.1091

Mr. Thanh Tùng: 093.909.8182

Thông số kỹ thuật

SWITCH DLINK
NUMBER OF PORTS	• 24 10/100Mbps Fast Ethernet ports
SWITCHING FABRIC	• 4.8 Gbps switching fabric
Standard	• IEEE 802.3 10BASE-T Ethernet (twisted pair copper) • IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) • ANSI/IEEE 802.3 NWay auto-negotiation • IEEE 802.3x flow control • IEEE 802.3az EEE function
Protocol	• CSMA/CD
Data Transfer Rates	• Fast Ethernet • 100 Mbps Half-Duplex • 200 Mbps Full-Duplex • Ethernet • 10 Mbps Half-Duplex • 20 Mbps Full-Duplex
Topology	• Star
Network Cables	• 10BASE-T: • UTP CAT 3/4/5/5e (100 m max.) • EIA/TIA-586 100-ohm STP (100 m max.) • 100BASE-TX • UTP CAT 5/5e (100 m max.) • EIA/TIA-568 100-ohm STP (100 m max.)
Media Interface Exchange	Auto MDI/MDIX adjustment for all ports
LED Indicators	• Per port: • Link/Activity • Per device: • Power
Transmission Method	• Store-and-forward
MAC Address Table	• 8K entries per device
MAC Address Learnin	• Automatic update
Packet Filtering/Forwarding Rates (half duplex)	• 148,800 pps for 100 M • 14,880 pps for 10 M
Power Consumption	• Standard Power Consumption: 1.17 Watts • Maximum Power Consumption: 2.8 Watts
Heat Dissipation	• Maximum Heat Dissipation: 9.5536 BTU/h
MTBF	810,880 hours
DIMENSIONS (L X W X H)	• 282 x 150 x 44 mm (11.1 x 5.91 x 1.73 inches)
Weight	1.14 kg (2.51 lbs)

Mô tả sản phẩm

With the D-Link 24-Port 10/100 Unmanaged Desktop or Rackmount Switch, you can easily expand your business or home network by adding more computers and devices, each achieving speeds up to 200 Mbps per port in full-duplex mode. Quickly and securely connect employees working in small offices with one another and all of the servers, printers, and other devices they use. High performance and reliable connectivity help speed file transfers and data processing, improve network uptime, and keep your employees connected and productive.

Expand and Upgrade Your Network

The DES-1024D offers an economical way for SOHO and small to medium businesses (SMB) to benefit from high-speed networking. It provides twenty-four ports for easy expansion of your network and a quick way to upgrade your network to Fast Ethernet connectivity.

Easy to Install and Use

The DES-1024D does not require any configuration or software, making installation simple and hassle-free. With Auto-MDI/MDI-X support, there is no need for crossover cables when you are connecting to another switch or to a computer. Additionally, the DES-1024D will automatically sense if the connected network devices are running at 10Mbps or 100Mbps and adjust accordingly. Equipped with a comprehensive LED display, you can monitor the status and activity of every port at a glance.

Designed with the Environment in Mind

The DES-1024D is energy efficient and consumes low power. It uses recyclable packaging that helps reduce waste, complying with the WEEE directive. It’s innovatively designed to run cool and quiet without sacrificing performance.
